XDS X-LAB AD9
Frame

XDS X-LAB AD9

Weight850g
Year2024
CategoryFrame

Colourways2

The XDS X-LAB AD9 is a highly competent, World Tour-level aero road bike that delivers performance comparable to established Western brands at a significantly lower price, typically around $8,000 with Shimano Dura-Ace Di2, power meter, and carbon wheels. While praised for its stiffness, speed, and exceptional value, it is often criticized for a firm ride, non-configurable cockpit at purchase, and limited availability outside Asia. Lab and wind tunnel data show it is aerodynamically mid-pack, roughly 6.7 watts slower than a Cervélo S5 with rider, and weighs between 6.86 kg and 7.79 kg depending on size and setup.

Pros

  • Exceptional value: $8,000 for a World Tour-level bike with Dura-Ace Di2, power meter, and carbon wheels, compared to $13,500+ for similar Western brands.123
  • Stiff, responsive, and fast aero bike with excellent power transfer and snappy acceleration.134
  • Lightweight: 6.86-6.9 kg as tested (without pedals), among the lightest aero bikes ridden.352
  • Handling is planted at high speed and agile at low speed, comparable to WorldTour competitors.367
  • High-quality frame finish and paint, with gloss options that are easy to clean.561
  • Comfortable ride for an aero bike, with vertical compliance and ability to run wider tires.189
  • Customizable bar width and crank length at point of purchase (on some models).34
  • Power meter (Branta) accurate within 1 watt of a reference power meter.31
  • T47 threaded bottom bracket for easy maintenance and reliability.5210

Cons

  • Firm, chattery ride quality, especially with stock carbon-spoke wheels on rough roads.315
  • Non-configurable cockpit at point of sale (stem length, bar width) limits fit; only free replacement after purchase.657
  • Limited availability outside Asia/Europe; not easily purchased in the US or UK at launch.829
  • Aerodynamic performance is mid-pack, 6.7 watts slower than a Cervélo S5 with rider.36
  • Stock wheels are overly stiff and harsh; some reviewers recommend swapping them.35
  • Emotionally uninspiring ride; not as exciting as some competitors.967
  • Tight tire clearance: 32mm officially, 33mm just fits, with minimal gap.1037
  • Heavier frame (963g) and components (e.g., 37g aluminum spacer, steel bolts) than premium rivals like Tarmac.2

Key Facts

  • Weight as ridden ranges from 6.86 kg (size M, no pedals) to 7.79 kg (with pedals, cages, mount, and 30c tires), with complete bikes typically 6.8-7.2 kg.362
  • Frame weight is 963g (size 54), fork 383g; complete bike claimed 6.8 kg, measured 6.9 kg in one build.2
  • Wind tunnel testing at 40 km/h shows 33.94 W saving vs. a baseline Emonda ALR as bike only, and 6.76 W slower than the fastest bike (Cervélo S5) with rider; 0.4 W saving claimed vs. Canyon Aeroad is within margin of error.67
  • Price is $7,999-$8,000 USD with Shimano Dura-Ace Di2, power meter, and carbon wheels; frameset is $3,751 USD or 3,270€ from CYCLEGEAR.32711
  • Tire clearance is officially 32mm, with 33mm just fitting; fork clearance is tight with 30mm tires.1067
  • Uses T1100 and M40X carbon fiber in the frame, with a T47 threaded bottom bracket and UDH compatibility (except some early models with proprietary hanger).1210
  • Stock components include 165mm cranks on size M, 170mm on size L; handlebar width 38cm on M, 40cm on L; zero-offset seatpost; and one-piece cockpit.12
  • In-house Branta C50 wheels weigh 1,230-1,239g for 50mm depth, with 21-22mm internal and 28.5-30mm external widths, carbon spokes, and 72-tooth ratchet hub.231

Reviews & Ratings

NERO Cycling
01:05:24
How Good Is The Cheapest Tour de France Bike? (X-LAB AD9) | NERO Show

The reviewer discusses the XDS X-LAB AD9, a road bike widely touted as the cheapest World Tour-level bike, priced at $7,999 USD ($11,000 AUD). He notes it is stiff, light (6.86 kg as tested), and offers excellent value, with customizable bar width and crank length at purchase. However, it is not particularly comfortable, the stock wheels are overly stiff, and its aerodynamic performance is mid-pack. He considers it a fun, snappy bike with handling as good as anything he's ridden, but recommends swapping the wheels for a more comfortable ride.

November 18, 2026Watch on YouTube
GCN Tech
08:27
New XDS-Astana Team Pro Bikes | The Brand You’ve Never Heard Of

The reviewer discusses the XDS X-LAB AD9, an aero road bike from the fully Chinese brand XDS Carbon Tech, which will be used by the XDS Astana team in the 2025 World Tour. He notes it is designed to be aerodynamic yet not overly stiff, providing compliance for comfort across most races. The bike is equipped with Shimano Dura-Ace, Vision wheels and handlebars, and Prologo saddle and tape. The reviewer highlights its clearance for 32mm tires (33mm just fits), T47 bottom bracket, and a claimed weight of around 7.4 kg. He also compares it to the climbing model, the RT9.

January 01, 2025Watch on YouTube
Crank Works Bikes
08:45
Ready to talk about the X-Lab AD9?? This is the FASTEST bike you have never heard of 🤔.

The reviewer discusses the XDS X-LAB AD9, describing it as the fastest bike in the X-LAB range. He praises its responsive acceleration, comfortable ride, and high-end components, noting that every pedal stroke translates into acceleration. He highlights the bike's stiffness, lack of flex, and the effectiveness of its carbon wheels and spokes. The reviewer also mentions the bike's modern geometry, including shorter cranks and a zero-offset seatpost, which improved his riding position. He considers the bike an exceptional value for its price, offering elite-level components at a fraction of the cost of major brands.

July 09, 2026Watch on YouTube
David Arthur - Just Ride Bikes2 videos
14:39
The End of Expensive Bikes? X-Lab RS7 & AD9 First Look

The reviewer provides a first ride review of the XDS X-LAB AD9, an aerodynamic road bike used by the Astana team. He notes it is priced at $8,000 with top-tier Shimano Dura-Ace Di2, a power meter, carbon wheels, and a one-piece cockpit, significantly undercutting similar Western brands. He finds it stiff yet surprisingly smooth, with predictable handling similar to a SuperSix Evo or Aeroad. He praises progressive details like 165mm cranks and a zero-offset seatpost, but notes minor issues such as a slippery handlebar wrap and only one aerofoil included.

July 10, 2026Watch on YouTube
13:47
Are Chinese Superbikes Finally This Good? (X-Lab AD9 Review)

The reviewer discusses the XDS X-LAB AD9/RT9, a new aero road bike from a Chinese brand, highlighting its competitive pricing, high-end components, and performance. They note it is a fast, stiff, and well-equipped bike but lacks emotional appeal and has some minor fit and finish issues.

August 30, 2026Watch on YouTube
Mr Bagusla
10:02
The cheapest Tour de France Frame Team Astana XDS X-LAB AD9 IN Singapore 🇸🇬

The reviewer examines an XDS X-Lab AD9 frame, noting its uncertain model name but praising its marble and gold paint job, aerodynamic design, and stiff feel. He compares its design to the S-Works Venge and Cannondale, mentions Astana team usage, and speculates on weight and price without testing it.

September 15, 2026Watch on YouTube
GC Performance4 videos
10:59
HOW DOES IT RIDE?? My Ride Review of the *XDS X-LAB AD9* $8000

The reviewer provides a 500-mile review of the XDS X-LAB AD9, a high-end aero road bike. He praises its stiff, responsive ride quality, comparing it to the third-generation Specialized Venge, and highlights its exceptional value at $8,000 with full Shimano Dura-Ace. He notes that it is more chattery than some modern road bikes but appreciates the road feedback. The bike comes with well-considered stock components like zero-offset seatpost, 165mm cranks on size medium, and narrow handlebars. He mentions minor drawbacks such as the need to download an app to activate the power meter and wishes for wider internal rim widths. Overall, he considers it a killer choice for a high-end aero bike, outperforming competitors like the Canyon Aeroad in his experience.

April 07, 2026Watch on YouTube
17:24
The BICYCLE INDUSTRY is NOT Ready for This BIKE *XDS AD9 X-LAB*

The reviewer presents the XDS X-LAB AD9 as a new 2026 model race bike that he believes will challenge the bicycle industry. He highlights its professional specifications, competitive pricing under $9,000 USD, and performance features, noting it is used by Team Astana in the pro peloton. He shares his initial riding impressions and details the bike's components, aerodynamics, and design.

February 09, 2026Watch on YouTube
12:50
Chinese Bikes in the WORLD TOUR! *ASTANA XDS X-LABS AD9*

The reviewer presents the XDS X-LAB AD9 as a flagship road bicycle from a Chinese brand, notable for being raced by Team Astana and aiming to offer pro-level performance at a more affordable cost. He received the bike for a long-term review, provides a detailed walkthrough, and shares initial positive impressions, though pricing is not yet available for the US market.

October 13, 2025Watch on YouTube
08:26
My Ride REVIEW of the X-LAB AD9 SUPER BIKE

The reviewer does not mention the XDS X-LAB AD9 in the transcript. The bike discussed is referred to as the S-Lab, with no reference to XDS X-LAB AD9.

May 24, 2026Watch on YouTube
China Rides
10:25
What a XLAB Bicycle Shop in China is Like - XLAB AD9 Full Review

The reviewer provides an independent review of the XDS X-LAB AD9, a top-end World Tour road bike from XDS, noting its aggressive geometry, light weight, and impressive value. They compare it favorably to more expensive bikes like the Canyon Aeroad, highlighting its speed and comfort, but note that sizing and availability outside China may be issues.

February 20, 2026Watch on YouTube
Cyclingnews Tech
12:21
X-LAB AD9 Aero Bike Review - Is Buying Chinese Finally Worth It?

The reviewer evaluates the XDS X-LAB AD9, a Chinese aero road bike from XDS's performance line. He finds it a competent and unflappable race bike that holds its own against established World Tour brands, though it lacks excitement and has a non-configurable cockpit. Wind tunnel tests show it performs well but not at the very top, and on the road it offers stable handling, good sprinting, and decent climbing, with a weight of 7.79 kg.

May 07, 2026Watch on YouTube
FairWheelBikes
16:42
X-LAB AD9 The Specialized Tarmac Killer?

The reviewer analyzes the XDS X-LAB AD9, a top-tier road bike from XDS, calling it a potential 'Tarmac killer' due to its similar performance at a much lower price. He details a frame-up build with stock components, weighing each part, and compares it to the Specialized S-Works Tarmac. The reviewer finds the AD9 roughly equal in aerodynamics and handling but heavier, with a complete bike weight of 6.9 kg versus the Tarmac's 6.7 kg. However, at $8,000 versus $13,500, he considers it an exceptional value and a serious contender.

June 09, 2026Watch on YouTube
CADE Media
14:16
How Good Is The Cheapest Tour de France Bike? - X-LAB AD9

The reviewer examines the XDS X-LAB AD9, a Tour de France-level road bike from XDS that shares similarities with the Astana team's race bike. Priced at $7,999, it is significantly cheaper than many comparable WorldTour bikes. The reviewer highlights its aerodynamic frame, lightweight build (6.89 kg), and in-house components, while questioning the brand's marketing claims and noting some ride quality issues with the stock wheels. Overall, the reviewer considers it a high-performance, good-value option for racers, though not without compromises.

July 20, 2026Watch on YouTube
cyclingnews.com
X-Lab AD9 review: Holds its own against WorldTour competitors, but it isn’t as cheap as you might expect

The reviewer states that the XDS X-LAB AD9 is an extremely competent aero road bike that performs comparably to WorldTour competitors, with neutral handling and good sprinting capability, though it is not the most exciting ride and has some purchasing limitations.

March 25, 2026Read full review
X-LAB AD9

The XDS X-LAB AD9 is a carbon frameset from XDS, a major Chinese OEM that produces frames for many Western brands. It is ridden by the XDS Astana pro team and has generated interest as a potential alternative to big-name brands. The frame features aero design cues such as a horizontal junction at the fork-frame meeting point, a head tube reminiscent of Specialized's Speed Sniffer, and a skinny top tube. Availability is limited: it is not expected to have a 'chiner' version and may not retail outside Asia, though XDS is expanding into the US and EU markets. Pricing is around 3270€ from CYCLEGEAR, which ships to Europe from Asia. Tyre clearance is not specified in the linked article.

AI Summary

Pros

  • Looks like a good alternative to big brands
  • Aero design with appealing features (horizontal fork-frame junction, Speed Sniffer-like head tube, skinny top tube)
  • XDS is a major carbon frame manufacturer and OEM for many Western brands

more pros in the review

Cons

  • Not likely to have a cheaper 'chiner' version
  • May not retail outside of Asia (though this is changing)
  • Price is relatively high at 3270€ from CYCLEGEAR

more cons in the review

Key Points

  • XDS is one of the biggest carbon frame manufacturers and an OEM for many big Western brands.
  • The frame is ridden by the XDS Astana pro team.
  • Available from CYCLEGEAR for 3270€, shipping to EU from Asia.

more key points in the review

Purchase

Where to Buy

$2,999.00· 3 stores
View Deals

UCI Approved Equipment

UCI approval certifies that the shape of this equipment complies with the UCI technical regulations, so it may be used in sanctioned road, track and cyclo-cross races.

FrameForkApproved sizesApprovedFrame codeFork code
AD-9 / ZB02AD-9 / ZB02470–560 (5 sizes)May 24, 2024XDS-ZB02XDS-ZB02

From the UCI List of Approved Models of Framesets, version 2026.11.03. Open the UCI list

Specifications

Attributes

Frame TypeRoad
Frame MaterialCarbon
Brake MountFlat Mount Disc
Bottom BracketT47
SeatpostProprietary
Front Axle12x100mm Thru-Axle
Rear Axle12x142mm Thru-Axle
Max Tire Width32 mm
Headset Type1-1/8" → 1.5" Tapered (IS42/28.6 | IS52/40)
Shifting Support—
Max Chainring Size—
UDH Compatible—
Includes Cockpit—
Stack : Reach1.38
2024 Base

Included Components

XDS X-LAB AD9
Frame
850g
X-Lab branded cockpit
Handlebar
—
in-line seatpost
Seatpost
—
Total Weight850g
