RoadJunonFit's Hygge

JunonFit's Hygge Road HYGGE Aerodynamic Carbon Frame with WHEELTOP EDS TX Wireless Groupset, ELITEWHEELS ENT 2.0 Carbon Wheels, RYET 3D Printed Saddle.

July 10, 2025
I Built This Carbon Road Bike Using AliExpress Parts - Here's The Breakdown
00:08:44
JunonFit
I Built This Carbon Road Bike Using AliExpress Parts - Here's The Breakdown
Frame
HYGGE Aerodynamic carbon frame MODEL S CARBON FRAME, ROAD FRAME
www.aliexpress.com//item/100500521376733...@MyBikeParts
Weight: Frame weight: 1090g(size 49)+-/30g (painted with accessories mounted) Fork weight: 400g+-/20g (painted with axle thru mounted) Seat post weight: 210g+-/10g (painted with accessories mounted) +380g handlebar
€727.39
2090g
Wheel
ELITEWHEELS Carbon Wheels ENT 2.0 Disc Brake 700c Carbon Rim Center Lock Road Bike Wheelset UCI Quality Road Racing Wheelset
s.click.aliexpress.com/e/_DFAYnyz@MyBikeParts
€345.0
1620g
Handlebar
BUCKLOS Bicycle Handlebar Tapes Shock-Absorption Comfortable Cycling Handlebar Tape Road Bike Drop Bar Tape Road Bicycle Parts
s.click.aliexpress.com//s/NdpwztbAIgDMmxGbP8...@MyBikeParts
€6.79
66g
Saddle
RYET 3D Printed Bicycle Saddle Ultralight 120g Carbon Saddle 250x140mm Bike Seating for MTB Gravel Road Bike Seat Cycling parts
s.click.aliexpress.com//s/NdpwztbAIgDMmxGbP8...@MyBikeParts
€20.0
120g
Crankset
SENICX Road Bike 2x10 /11/12 Speed Crank Chainring WHEEL 50-34T 53-39T 36-52T 30-46T Double Chainring Road Bicycle Crankset
s.click.aliexpress.com//s/NdpwztbAIgDMmxGbP8...@MyBikeParts
€56.69
789g
Bottom Bracket
BUCKLOS Bicycle Bottom Bracket Sealed Bearing 24mm Bike BB BSA Threaded BB68/73 MTB Bottom Bracket Road Mountain Bike Parts
s.click.aliexpress.com//s/NdpwztbAIgDMmxGbP8...@MyBikeParts
€5.69
110g
Cassette
ZTTO MTB Road Bike 8/9/10/11/12 Speed Cassette 11v 25T/28T//30T/32T/34T/36T Sprocket K7 10v Bicycle Freewheel
s.click.aliexpress.com//s/NdpwztbAIgDMmxGbP8...@MyBikeParts
11-34: 380g
€10.89
380g
Chain
KMC Bike Chain X8 X9 X10 X11 X12 MTB Bicycle Chains 8 9 10 11 12 Speed Road Bike Current Mountain Bike for Shimano Bikes Part
s.click.aliexpress.com//s/NdpwztbAIgDMmxGbP8...@MyBikeParts
300g for 126L
€11.39
300g
Pedals
BUCKLOS MTB Self-locking Pedal For SPD System M8100 M9100 Bicycle Pedals Bearing Clipless Pedal with Cleat for Shimano
@MyBikeParts
€21.99
789g
Groupset
WHEELTOP EDS TX Road bike Groupset Electronic Wireless Carbon, alloy, 1/2*3-14s Speed
s.click.aliexpress.com/e/_oBwQat3@MyBikeParts
191+336+223+223 + 2x unknown disc brake + hoses (F: 135 ± 10g, R: 170 ± 10g)
€550.99
1300g
Front Brake
ZRACE Center Lock Brake Disc Rotor Strong Heat Dissipation Floating 140mm 160mm 180mm, for MTB / Road
www.aliexpress.us//item/325680604043780...@MyBikeParts
Size: 140mm / 160mm / 180mm Weight: 121g / 143g / 160g / 190 Total Weight: 140+160
€6.67
300g
Tubes
RideNow TPU Bike Inner Tube 700C 700x18 23 25 28 32 35 37 40 47C Road Bicycle Tire MTB Bike Camera 29x1.5 1.75 1.9 pneu aro
s.click.aliexpress.com//s/NdpwztbAIgDMmxGbP8...@MyBikeParts
36g: 18-32C
€6.49
2x 36.0g = 72g
Accessories
CYCLAMI 360 Rotating Mount Holder For Go Pro 8-13 Insta360 One X2 X3 X4 DJI Camera Accessories Bike Mount for IGS Garmin XOSS
s.click.aliexpress.com//s/NdpwztbAIgDMmxGbP8...@MyBikeParts
€11.99
71g

Bike Geometry

View on Bike Insights
381mm 522mm

Primary Measurements

Stack521.5 mm
Reach381.0 mm
Stack/Reach Ratio1.37
Wheelbase988.0 mm

Frame Angles

Head Tube Angle71.0°
Seat Tube Angle73.5°
Top Tube Slope5.67°

Tube Lengths

Head Tube117.5 mm
Seat Tube490.0 mm
Effective Top Tube535.5 mm
Chainstay410.0 mm

Fork & Handling

Fork Offset/Rake45.0 mm
Fork Length375.31 mm
Trail69.8 mm (long/stable)
Mechanical Trail66.0 mm

Bottom Bracket & Clearance

BB Drop70.0 mm
BB Height271.0 mm
Tire Clearance77.5 mm (with 170mm cranks)
Pedal Clearance101.0 mm (with 170mm cranks)

Additional Measurements

Front Center588.5 mm
Chainstay (Horizontal)404.0 mm
Wheel Flop21.5 mm

Build Summary

Total Weight8,007g
Total Prices
EUR€1781.97
