MyBikeParts
Frame
LCR018-D
Price includes:
- Handlebar + Stem (Integrated)
- Fork,
- Axles,
- Storage Door + Bag,
- Seat-Post,
- Custom Painting and Shipping
-> Unknown Paint weight.
$1004.0 (€862.54)
1004g
LC Metal door for downtube storage
-
55g
Fork
LightCarbon 700C Disc Brake Gravel Carbon Fork Racing Gravel Fork
-
423g
Handlebar
BUCKLOS Bicycle Handlebar Tape Comfortable Anti Slip Bike Handle Bartape Strap Shock Absorbing Road Racing Cycling Grip Tapes
$8.19 (€7.04)
66g
Lightcarbon HBR17
-
303g
Headset (LC) + Batterymount
-
172g
Seatpost
Full Carbon Seat Post Zero/15mm Offset
-
166g
LC: Batterymount, Gummi, Seat Post Screw
-
43g
Saddle
MIXED Ultra Light 7D MAX Carbon Saddle Road Bike 140MM Bicycle Seat 108G Cycling Parts
$42.74 (€36.72)
108g
Crankset
4iiii precision powermeter
Old version - still have a crankarm left here.
€299.0
10g
Bottom Bracket
Rotor T4724
€57.99
100g
Chain
SHIMANO DEORE SLX XT XTR M6100 M7100 M8100 M9100 12Speed Chain for Mountain Bike Bicycle 12S Current MTB Parts with QUICK LINK
M8100
€30.61
250g
Pedals
Shimano Klickpedale PD-R550
€67.99
310g
Groupset
Brake Hoses etc.
- SM-BH90 (hoses): 48 g
- Mineral oil: 50 g
- Caliper bolts (4x): 18 g
- SM-MA-R160D/D (adapter + bolts): 38 g
-
140g
Shimano 105 Di2 R7150 Gruppe 2x12 34-50
- FC-R7100: 765 g
- RD-R7150: 302 g
- FD-R7150: 142 g
- BT-DN300: 53 g
- CS-R7101: 361 g
- CN-M7100: 252 g
- BR-R7170 (pair): 246 g
- ST-R7170 (pair): 423 g
- E W-SD300 (wires): 20 g
Already owned by me so not bought new
€929.0
2564g
Front Brake
SHIMANO L05A Resin Disc Brake Pads with Fin MTB Road Bike for DEORE XT SLX ULTEGRA M8100 M7100 R9150 R7100 R8050 R7000
$10.33 (€8.87)
2x 16.0g = 32g
ZRACE Center Lock Disc Rotor bike brake rotor Strong heat dissipation floating rotor 140mm 160mm 180mm MTB / Road disc brake
160mm: 143g + 140mm 121g
ca. 13 EUR
€13.0
264g
Wheel
XMCarbonspeed CS-D50CU-33 Disc brake carbon road + Pillar Wing20
- personally build the wheelset from Peter's rims + hub + spoke recommendations
- Price estimated
€700.0
1265g
LC Thru-Axles
27g Front, 35g Back
-
64g
Tires
2x SCHWALBE Gravel Reifen 28x1.35 | 35-622 G-One Speed SuperGround TLE Addix SpeedGrip schwarz | 28x1.35 | 35-622 | ohne Schlauch | 2X442503O
€85.85
2x 330.0g = 660g
SCHWALBE CLIK VALVE TUBELESS VENTIL | 80 mm | 3530
€23.9
2x 18.0g = 36g
Tubes
Stans 60ml per tire
€5.0
2x 60.0g = 120g
Accessories
€99.0
78g
XXX 3K ultralightsided carbon fiber mountain bike road bike bottle cage 18g water bottle holder water cup holder
€11.19
2x 18.0g = 36g
LC Garmin Mount
-
40g
iGS630S Fahrradcomputer
€169.69
100g
LC Storage Bag
-
40g
Weight & Price Breakdown
Weight Distribution
Price Distribution
Bike Geometry
View on Bike InsightsPrimary Measurements
Stack552.0 mm
Reach377.0 mm
Stack/Reach Ratio1.46
Wheelbase992.2 mm
Frame Angles
Head Tube Angle72.0°
Seat Tube Angle74.0°
Top Tube Slope10.09°
Tube Lengths
Head Tube137.0 mm
Seat Tube480.0 mm
Effective Top Tube535.0 mm
Chainstay415.0 mm
Fork & Handling
Fork Offset/Rake51.0 mm
Fork Length374.54 mm
Trail60.4 mm (mid/neutral)
Mechanical Trail57.5 mm
Bottom Bracket & Clearance
BB Drop78.0 mm
BB Height273.0 mm
Tire Clearance68.8 mm
(@ 170mm cranks)
(@ 170mm cranks)
Pedal Clearance103.0 mm
(@ 170mm cranks)
(@ 170mm cranks)
Additional Measurements
Front Center589.8 mm
Chainstay (Horizontal)407.6 mm
Wheel Flop17.8 mm
