ICAN Cycling A22 AERO Disc Road Frame

Reviews & Ratings

00:19:27

ICAN Cycling A22 Road Bike Frame... Roast ends in a Flame Out

The reviewer, Hambini, evaluates the ICAN Cycling A22 AERO Disc Road Frame and finds it remarkably good for its price. He praises the machining and facing of the bottom bracket and disc brake mounts, the knurled seatpost clamp, the clean internal finish, and the overall attention to detail. He notes minor paint imperfections but considers them negligible. The frame is compared favorably to a Giant TCR, which had internal defects.

AI Summary

Pros

Bottom bracket and brake mounts are machined and faced to spec
Seatpost clamp is knurled to prevent slipping
Handlebar area has roughened surface for grip
Internal frame finish is very clean with minimal excess adhesive
All components fit well and are well-made
Geometry is straight and parallel
Fork and through axles are perpendicular within reason
Good value for money

Cons

Paint finish around some areas is not perfect (minor)
Aero handlebars limit mounting options and tilt adjustment

Key Points

Frame is carbon construction, made in Shenzhen, China
BB86 bottom bracket, measured 40.97 mm (spec 40.95-41 mm)
Includes frame, fork, seatpost, handlebars, thru axles, and spacers
Handlebar + stem weight: 414-415 grams
Fork weight: 445 grams (includes bottom bearing)
Frame weight: just over 1 kg
Integrated cable routing with option for external routing
Seatpost clamp uses two adjustment points (front and rear)

Purchase

Where to Buy

ICAN Cycling A22 AERO Disc Road Frame|Carbon Road bike Disc Frame[NEW 2021]

icancycling.com

🇺🇸$730.00

4.8 (12)

Checked about 1 hour ago

$730.00· icancycling.com

View Deals

Specifications

Attributes

Frame TypeRoad

Frame MaterialCarbon

Brake MountFlat Mount Disc

Bottom BracketBB86 Press Fit

SeatpostProprietary

Front Axle12x100mm Thru-Axle

Rear Axle12x142mm Thru-Axle

Max Tire Width (mm)28

Headset Type1.5" Straight

Di2 CompatibleYes

Max Chainring Size—

UDH Compatible—

Geometry on BikeInsights

2021 Base

XS/45 S/48 M/51 L/54 XL/57

Included Components

ICAN Cycling A22 AERO Disc Road Frame

Frame

1,058g

ICAN A22 Seatpost

Seatpost

182g

ICAN AO22 Fork

Fork

425g

ICAN HBA22 Handlebar

Handlebar

—

Headsets

Headset

—

Stem

—

Total Weight1,665g
